6 x 19 CLASS STAINLESS STEEL, Type 304 – 6 x 19 stainless steel wire rope is a general purpose steel wire rope that’s widely used in the many industries and performs exceptionally well in marine environments given it’s resistance to sea water.
| Dia. in Inches | Approx. Wt. per Ft. in Lbs. | Breaking Strength in Pounds*/** |
|---|---|---|
| 7/16″ | 0.35 | 16,300 |
| 1/2″ | 0.46 | 22,800 |
| 9/16″*** | 0.59 | 28,500 |
| 5/8″*** | 0.72 | 35,000 |
| 3/4″*** | 1.04 | 49,600 |
| 7/8″*** | 1.42 | 66,500 |
| 1″*** | 1.85 | 85,400 |
** Type 316 not covered by Federal Specification RR-W-410E – breaking strength may vary.
*** Actual construction 6 x 25 (FI)
